Storm classes

Classes

struct  ConjugateGradientOnly< Size, Precision >
 Class for performing optimization with Conjugate Gradient, where only the derivatives are available. More...
class  NullGraphics
 Graphics class which does absoloutely nothing. More...
class  DataForMCMC
 Closure hoding the data required do use GibbsSampler2 See FitSpots for naming of variables. More...
struct  SampledBackgroundData
 Closure holding image data generated using samples drawn from the model. More...
struct  SpotNegProbabilityDiffWithSampledBackground
 Compute the derivative of the negative log probability with respect to the parameters of one spot, given some samples of the other spots. More...
class  FreeEnergyHessian
 Class for computing the Hessian of the negative free energy. More...
class  FitSpots
 Mega class which actually does the meat of the spot fitting. More...
class  FitSpotsGraphics
 Graphics class for FittingSpots. More...
class  UserInterfaceCallback
 Callback class used by FitSpots to provide enough hooks for a user interface. More...
class  SampledMultispot::GibbsSampler
 Draw samples from the spot states given the spots positions and some data. More...
class  SampledMultispot::GibbsSampler2
 Gibbs sampling class which masks spots to reduce computation. More...

Functions

auto_ptr< UserInterfaceCallback > null_ui ()
auto_ptr< FitSpotsGraphics > null_graphics ()
void get_spot_pixels (const vector< ImageRef > &pixels, const Vector< 4 > &spot, vector< int > &out)
StateParameters parse_log_file (istream &in)
double brightness_motion_limit (double mu, double sigma, bool not_one)
void fit_spots_new (const vector< Image< float > > &ims, StateParameters &p, ofstream &save_spots, FitSpotsGraphics &gr)
void fit_spots_new (const vector< Image< float > > &ims, StateParameters &p, ofstream &save_spots, FitSpotsGraphics &gr, UserInterfaceCallback &ui)
template<class B >
double spot_shape_s (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class B >
std::pair< double,
TooN::Vector< 4 > > 		spot_shape_diff_position (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class B >
std::tr1::tuple< double,
TooN::Vector
< 4 >, TooN::Matrix< 4 > > 		spot_shape_hess_position (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class B >
std::tr1::tuple< double,
TooN::Vector
< 2 >, TooN::Matrix< 2 > > 		spot_shape_hess (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class B >
std::pair< double,
TooN::Vector< 2 > > 		spot_shape_diff (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class B >
double spot_shape (const TooN::Vector< 2 > &x, const TooN::Vector< 4, double, B > &phi)
template<class Base >
std::tr1::tuple< double,
TooN::Vector
< 2 >, TooN::Matrix< 2 > > 		log_probability_spot_hess (const CVD::SubImage< float > &im, double variance, const TooN::Vector< 4, double, Base > &spot_parameters)
template<class Base >
std::pair< double,
TooN::Vector< 2 > > 		log_probability_spot_diff (const CVD::SubImage< float > &im, double variance, const TooN::Vector< 4, double, Base > &spot_parameters)
template<class Base >
double log_probability_spot (const CVD::SubImage< float > &im, double variance, const TooN::Vector< 4, double, Base > &spot_parameters)
double log_normal_std (double mu, double sigma)
double log_normal_mode (double mu, double sigma)
double log_log_normal (double x, double mu, double sigma)
double diff_log_log_normal (double x, double mu, double sigma)
double hess_log_log_normal (double x, double mu, double sigma)

Function Documentation

auto_ptr<UserInterfaceCallback> null_ui ( )

Factory function to generate an instance of NullGraphics.

Definition at line 62 of file multispot5.cc.

Referenced by fit_spots_new().

{
    return auto_ptr<UserInterfaceCallback>(new NullUICallback);
}
auto_ptr<FitSpotsGraphics> null_graphics ( )

Factory function to generate an instance of NullGraphics.

Definition at line 89 of file multispot5.cc.

Referenced by Java_ThreeBRunner_call(), and mmain().

{
    return auto_ptr<FitSpotsGraphics>(new NullGraphics);
}
void get_spot_pixels ( const vector< ImageRef > &  pixels,
const Vector< 4 > &  spot,
vector< int > &  out
)

Which pixels belong to a given spot? Find the indices of those pixels.

Definition at line 886 of file multispot5.cc.

Referenced by FitSpots::optimize_each_spot_in_turn_for_several_passes(), and FitSpots::try_modifying_model().

{
    //Go out to three sigma

    vector<ImageRef> pix = getDisc(spot[1]*6 + 1);
    out.resize(0);
    ImageRef offset = ir_rounded(spot.slice<2,2>());
    for(unsigned int j=0; j < pix.size(); j++)
    {
        int pos = lower_bound(pixels.begin(), pixels.end(), pix[j] + offset) - pixels.begin();
        if(pos != (int)pixels.size() && pixels[pos] == pix[j] + offset)
            out.push_back(pos);
    }

    if(out.size() == 0)
    {
        cout << "********************************\n";
        cout << "********************************\n";
        cout << "********************************\n";
        cout << "********************************\n";
        cout << "********************************\n";
        cout << "Oe noes!11one\n";
        cout << pix.size() << endl;
    }
}
StateParameters parse_log_file ( istream &  in)

Parser for multispot 5 log files.

Log files are mostly line oriented and contain various records

The main records are:

Iteraton: #ITNUM MAIN: <list of spot parameters>

Pass: #PASSNUM MT19937 <random number generator state> PASS#PASSNUM: <list of spot parameters> ENDCHECKPOINT

Note that MAIN is redundant since it will be the same as the following PASS 1 (or the first pass computed if restoring from a checkpoint).

Data should only be considered valid after ENDCHECKPOINT has been read

Iteration is written once per iteration, not once per pass. (FIXME)

Which moron invented this file format???

Note that the file format hasn't beren fixed, so that the output can easily be compared to the output of the historic version which is known to be good.

Parameters:
inStream to parse file from

Definition at line 986 of file multispot5.cc.

References StateParameters::iteration, StateParameters::pass, StateParameters::pixels, StateParameters::rng, split(), StateParameters::spots, and xtoa().

Referenced by mmain().

{
    //A line read from the file
    string line;

    //State lines known to be OK
    string rngline, passline, iterationline;
    bool state_ok=0;

    //State lines read in, with flags of goodness
    string new_rngline, new_passline, new_iterationline;
    bool new_rngline_ok=0, new_passline_ok=0, new_iterationline_ok=0;

    unsigned int lineno=0;
    bool doing_gvars = 0;

    vector<ImageRef> pixels;

    while(!in.eof())
    {
        getline(in, line);
        if(in.fail())
            break;

        lineno++;

        if(line == "ENDGVARLIST")
        {
            if(!doing_gvars)
                throw LogFileParseError("Spurious end of GVars");
            doing_gvars = 0;
        }
        else if(doing_gvars)
        {
            GUI.ParseLine(line);
        }
        else if(line == "BEGINGVARLIST")
        {
            doing_gvars = 1;
        }
        if(line.substr(0, 11)  == "Iteration: ")
        {
            new_iterationline = line;
            new_iterationline_ok = true;
        }
        else if(line.substr(0, 4) == "PASS")
        {
            new_passline = line;
            if(new_passline_ok)
                throw LogFileParseError("Duplicate PASS on line " + xtoa(lineno));
            new_passline_ok = true;
        }
        else if(line.substr(0, 8) == "MT19937 ")
        {
            new_rngline = line;
            if(new_rngline_ok)
                throw LogFileParseError("Duplicate MT19937 on line " + xtoa(lineno));

            new_rngline_ok = true;

        }
        else if(line == "ENDCHECKPOINT")
        {
            if(new_passline_ok && new_rngline_ok && new_iterationline_ok)
            {
                iterationline = new_iterationline;
                rngline = new_rngline;
                passline = new_passline;
            }
            else
                throw LogFileParseError("Reached checkpoint with missing data: "
                         "it=" + xtoa(new_iterationline_ok) +
                        " pa=" + xtoa(new_passline_ok) +
                        " rg=" + xtoa(new_rngline_ok) + " on line " + xtoa(lineno));

            //Don't reset iteration since it only appears once for each entire
            //set of passes.
            new_rngline_ok = 0;
            new_passline_ok = 0;

            state_ok = true;
        }
        else if(line.substr(0, 7) == "PIXELS ")
        {
            vector<string> l = split(line);
            if( (l.size() - 1)%2 == 0)
            {
                int n = (l.size()-1)/2;
                pixels.resize(n);
                for(int i=0; i < n; i++)
                {
                    pixels[i].x = atox<int>(l[i*2+1+0], "pixels");
                    pixels[i].y = atox<int>(l[i*2+1+1], "pixels");
                }
            }
            else
                throw LogFileParseError("Bad PIXELS line");
        }
    }

    if(!state_ok)
        throw LogFileParseError("No state found");

    if(pixels.size() == 0)
        throw LogFileParseError("No pixels, or pixels is empty");

    //Now parse the lines
    StateParameters p;
    vector<string> l;

    //Parse the iterations
    l = split(iterationline);
    p.iteration = atox<int>(l[1], "iteration");

    //Parse the random number generator
    p.rng =shared_ptr<MT19937>(new MT19937);
    {
        istringstream rng_s(rngline);
        try{
            p.rng->read(rng_s);
        }
        catch(MT19937::ParseError p)
        {
            throw LogFileParseError("Error parsing MT19937");
        }
    }

    //Parse PASS and the listing of spots
    l = split(passline);
    if( (l.size() - 1 ) % 4 == 0)
    {
        p.pass = atox<int>(l[0].substr(4), "pass");

        for(unsigned int i=0; i < (l.size()-1)/4; i++)
        {
            cout << l[i*4+1+0] << endl;
            cout << l[i*4+1+1] << endl;
            cout << l[i*4+1+2] << endl;
            cout << l[i*4+1+3] << endl;
            p.spots.push_back(makeVector(
                        atox<double>(l[i*4+1+0], "spot"),
                        atox<double>(l[i*4+1+1], "spot"),
                        atox<double>(l[i*4+1+2], "spot"),
                        atox<double>(l[i*4+1+3], "spot")));
        }

    }
    else
        throw LogFileParseError("Wrong number of elements in PASS line");

    //Set up the pixels (oh god the pixels)
    p.pixels = pixels;

    return p;
}
double brightness_motion_limit ( double  mu,
double  sigma,
bool  not_one
)

How far should steps in brightness be limited to?

Definition at line 1334 of file multispot5.cc.

References log_normal_std().

{
    if(not_one)
        return log_normal_std(mu, sigma);
    else
        return 1;
}
void fit_spots_new ( const vector< Image< float > > &  ims,
StateParameters &  p,
ofstream &  save_spots,
FitSpotsGraphics &  gr
)

Wrapper function for using FitSpots.

Definition at line 2081 of file multispot5.cc.

References null_ui(), and FitSpots::run().

Referenced by mmain().

{
    auto_ptr<UserInterfaceCallback> ui = null_ui();
    FitSpots fit(ims, gr, *ui, p, save_spots);
    fit.run();
}
void fit_spots_new ( const vector< Image< float > > &  ims,
StateParameters &  p,
ofstream &  save_spots,
FitSpotsGraphics &  gr,
UserInterfaceCallback &  ui
)

Wrapper function for using FitSpots.

Definition at line 2090 of file multispot5.cc.

References FitSpots::run().

{
    try{
        FitSpots fit(ims, gr, ui, p, save_spots);
        fit.run();
    }
    catch(UserInterfaceCallback::UserIssuedStop)
    {
    }
}
template<class B >
double spot_shape_s ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

See spot_shape()

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$
Returns:
$s(\Vec{x}, \Vec{\phi}) $

Definition at line 17 of file storm.h.

Referenced by spot_shape(), spot_shape_diff(), spot_shape_diff_position(), spot_shape_hess(), and spot_shape_hess_position().

{
    return -norm_sq(x - phi.template slice<2,2>()) / (2*phi[1]*phi[1]);
}
template<class B >
std::pair<double, TooN::Vector<4> > spot_shape_diff_position ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

Compute the spot shape and its derivative with respect to posision.

See also spot_shape()

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$

Definition at line 27 of file storm.h.

References spot_shape_s(), and sq().

{
    using namespace TooN;

    double s = spot_shape_s(x, phi);
    double r_2_pi = sqrt(2*M_PI);

    double prob = exp(s) * phi[0]/(phi[1]*r_2_pi);

    Vector<4> deriv = (exp(s) / (phi[1]*r_2_pi)) *
                           makeVector(1,
                                      -phi[0] * (1 + 2*s)/phi[1],
                                      (x[0] - phi[2])*(phi[0]/sq(phi[1])),
                                      (x[1] - phi[3])*(phi[0]/sq(phi[1])));
    return std::make_pair(prob, deriv);
}
template<class B >
std::tr1::tuple<double, TooN::Vector<4>, TooN::Matrix<4> > spot_shape_hess_position ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

Compute the spot shape and its Hessian with respect to posision.

See also spot_shape()

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$

Definition at line 49 of file storm.h.

References spot_shape_s(), and sq().

{
    using namespace TooN;
    using namespace std::tr1;

    double s = spot_shape_s(x, phi);
    double r_2_pi = sqrt(2*M_PI);

    double es = exp(s);

    double prob = es * phi[0]/(phi[1]*r_2_pi);

    Vector<4> deriv = (es / (phi[1]*r_2_pi)) *
                           makeVector(1,
                                      -phi[0] * (1 + 2*s)/phi[1],
                                      (x[0] - phi[2])*(phi[0]/sq(phi[1])),
                                      (x[1] - phi[3])*(phi[0]/sq(phi[1])));

    Matrix<4> hess;
    hess[0][0] = 0;

    hess[0][1] = -es*(1+2*s) / (phi[1] * phi[1] * r_2_pi);
    hess[1][0] = hess[0][1];

    hess[0][2] = es * (x[0] - phi[2]) / (pow(phi[1], 3)*r_2_pi);
    hess[2][0] = es * (x[0] - phi[2]) / (pow(phi[1], 3)*r_2_pi);

    hess[0][3] = es * (x[1] - phi[3]) / (pow(phi[1], 3)*r_2_pi);
    hess[3][0] = es * (x[1] - phi[3]) / (pow(phi[1], 3)*r_2_pi);

    hess[1][1] = 2*phi[0]*es*(1 + 5*s + 2*s*s) / ( pow(phi[1], 3) * r_2_pi);

    hess[1][2] = -phi[0] * es * (3 + 2*s) * (x[0] - phi[2]) / (pow(phi[1], 4) * r_2_pi);
    hess[1][3] = -phi[0] * es * (3 + 2*s) * (x[1] - phi[3]) / (pow(phi[1], 4) * r_2_pi);

    hess[2][1] = hess[1][2];
    hess[3][1] = hess[1][3];

    hess[2][2] = phi[0] * es * (sq(x[0] - phi[2]) - sq(phi[1])) / (r_2_pi * pow(phi[1], 5));
    hess[3][3] = phi[0] * es * (sq(x[1] - phi[3]) - sq(phi[1])) / (r_2_pi * pow(phi[1], 5));

    hess[2][3] = phi[0] * es * (x[0] - phi[2])*(x[1] - phi[3]) / (r_2_pi * pow(phi[1], 5));
    hess[3][2] = hess[2][3];


    return make_tuple(prob, deriv, hess);
}
template<class B >
std::tr1::tuple<double, TooN::Vector<2>, TooN::Matrix<2> > spot_shape_hess ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

Value of the spot, given the parameters and input location.

The spot is described by the following formula:

\[ \mu(\Vec{x}, \Vec{\phi}) = \frac{\phi_1}{\phi_2\sqrt(2\pi)} e^s, \]

where

\[ s = -\frac{(x_1 - \phi_3)^2 + (x_2 - \phi_4)^2}{2\phi_2^2}. \]

This describes a generic blobby spot function of a variable size. The light output can be tuned by varying $\phi_1$, and the level of blur can be changed independently by varying $\phi_2$. The derivative is:

\begin{eqnarray} \frac{\partial \mu}{\partial \phi_1} &=& \frac{1}{\phi_2\sqrt{2\pi}}e^s\\ \frac{\partial \mu}{\partial \phi_2} &=& -\frac{\phi_1}{\phi_2^2\sqrt{2\pi}}e^s(1 + 2s) \end{eqnarray}

And the hessian is:

\begin{eqnarray} \frac{\partial^2 \mu}{\partial \phi_1^2} &=& 0\\ \frac{\partial^2 \mu}{\partial\phi_1 \partial \phi_2} &=& -\frac{1}{\phi_2^2\sqrt{2\pi}}e^s(1 + 2s)\\ \frac{\partial^2 \mu}{\partial \phi_2^2} &=& \frac{2\phi_1}{\phi_2^3\sqrt{2\pi}}e^s(1 + 5s + 2s^2) \end{eqnarray}

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$
Returns:
$\mu(\Vec{x}, \Vec{\phi}) $

Definition at line 124 of file storm.h.

References spot_shape_s().

Referenced by log_probability_spot_hess().

{
    double s = spot_shape_s(x, phi);
    double r_2_pi = sqrt(2*M_PI);

    double prob = exp(s) * phi[0]/(phi[1]*r_2_pi);
    TooN::Vector<2> deriv = (exp(s) / (phi[1]*r_2_pi)) * TooN::makeVector(1, -phi[0] * (1 + 2*s)/phi[1]);
    TooN::Matrix<2> hess;

    hess[0][0] = 0;
    hess[0][1] = -exp(s)*(1+2*s) / (phi[1] * phi[1] * r_2_pi);
    hess[1][0] = hess[0][1];
    hess[1][1] = 2*phi[0]*exp(s)*(1 + 5*s + 2*s*s) / ( pow(phi[1], 3) * r_2_pi);

    return std::tr1::make_tuple(prob, deriv, hess);
}
template<class B >
std::pair<double, TooN::Vector<2> > spot_shape_diff ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

see spot_shape_hess()

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$
Returns:
$\mu(\Vec{x}, \Vec{\phi}) $

Definition at line 146 of file storm.h.

References spot_shape_s().

Referenced by log_probability_spot_diff().

{
    double s = spot_shape_s(x, phi);
    double r_2_pi = sqrt(2*M_PI);

    double prob = exp(s) * phi[0]/(phi[1]*r_2_pi);
    TooN::Vector<2> deriv = (exp(s) / (phi[1]*r_2_pi)) * TooN::makeVector(1, -phi[0] * (1 + 2*s)/phi[1]);
    return std::make_pair(prob, deriv);
}
template<class B >
double spot_shape ( const TooN::Vector< 2 > &  x,
const TooN::Vector< 4, double, B > &  phi
)

see spot_shape_hess()

Parameters:
x$\Vec{x}$
phi$\Vec{\phi}$
Returns:
$\mu(\Vec{x}, \Vec{\phi}) $

Definition at line 162 of file storm.h.

References spot_shape_s().

Referenced by log_probability_spot().

{
    double s = spot_shape_s(x, phi);
    double r_2_pi = sqrt(2*M_PI);

    // FIXME FIXME FIXME and don't forget to fix the HESSIAN AND DERIVATIVE
    // Should be:              1/(2 pi s^2)  for two dimensions
    //                             vvvvvvvvvvvvv    http://lol.i.trollyou.com/
    double prob = exp(s) * phi[0]/(phi[1]*r_2_pi);


    return prob;
}
template<class Base >
std::tr1::tuple<double, TooN::Vector<2>, TooN::Matrix<2> > log_probability_spot_hess ( const CVD::SubImage< float > &  im,
double  variance,
const TooN::Vector< 4, double, Base > &  spot_parameters
)

Find the log probability of an image patch, assuming zero base-line mean and the given variance.

This function makes use of the spot shape. It is assumed that the centre pixel of the image is at 0,0. Since the noise is Gaussian:

\begin{eqnarray} P(\text{image}) &=& \prod_{\Vec{x} \in \text{pixels}} \frac{1}{\sqrt{2\pi\sigma^2}}e^{-\frac{(I(\Vec{x}) - \mu(\Vec{x}, \Vec{\phi}))^2}{2\sigma^2}} \\ \ln P(\text{image}) &=& \sum_{\Vec{x} \in \text{pixels}} -\frac{(I(\Vec{x}) - \mu(\Vec{x}, \Vec{\phi}))^2}{2\sigma^2} - \frac{N}{2} \ln {2 \pi \sigma^2}, \end{eqnarray}

where I is the image, and N is the number of pixels. See also log_probability_no_spot and $\mu$ (spot_shape). The derivatives are:

\begin{eqnarray} \frac{\partial \ln P(I)}{\partial \phi_0} &=& \frac{1}{\sigma^2} \sum_{\Vec{x}}(I_{\Vec{x}} - \mu(\Vec{x},\Vec{\phi})) \frac{\partial}{\partial \phi_0}\mu(\Vec{x}, \Vec{\phi})\\ \frac{\partial^2 \ln P(I)}{\partial \phi_0 \partial \phi_1} &=& \frac{1}{\sigma^2} \sum_{\Vec{x}}(I_{\Vec{x}} - \mu(\Vec{x},\Vec{\phi})) \frac{\partial^2}{\partial \phi_0 \partial \phi_1}\mu(\Vec{x}, \Vec{\phi}) - \frac{\partial}{\partial \phi_0}\mu(\Vec{x},\Vec{\phi}) \frac{\partial}{\partial \phi_1}\mu(\Vec{x},\Vec{\phi}) \end{eqnarray}

Parameters:
imImage
variance$\sigma^2$
spot_parameters$\Vec{\phi}$
Returns:
The log probability

Definition at line 217 of file storm.h.

References spot_shape_hess(), and sq().

{
    using namespace TooN;
    using namespace std::tr1;

    //-1 because if the image is 3x3, ie 0,1,2 then 1,1 is the centre.
    //If it is 2x2, ie 0,1 then .5,.5 is the centre
    Vector<2> centre = makeVector((im.size().x-1) / 2.0, (im.size().y-1) / 2.0);

    double logprob_part=0;
    Vector<2> diff = Zeros;
    Matrix<2> hess = Zeros;
    for(int y=0; y < im.size().y; y++)
        for(int x=0; x < im.size().x; x++)
        {
            Vector<2> d = TooN::makeVector(x, y) - centre;

            double mu;
            Vector<2> diff_mu;
            Matrix<2> hess_mu;
            tie(mu, diff_mu, hess_mu) = spot_shape_hess(d, spot_parameters);

            double e = im[y][x] - mu;

            logprob_part += -sq(e);
            diff         += diff_mu * e;
            hess         += e * hess_mu - diff_mu.as_col() * diff_mu.as_row();
        }
    return make_tuple(   logprob_part / (2*variance) - im.size().area() * log(2*M_PI*variance)/2,
                        diff / variance,
                        hess / variance);
}
template<class Base >
std::pair<double, TooN::Vector<2> > log_probability_spot_diff ( const CVD::SubImage< float > &  im,
double  variance,
const TooN::Vector< 4, double, Base > &  spot_parameters
)

See log_probability_spot_hess.

Parameters:
imImage
variance$\sigma^2$
spot_parameters$\Vec{\phi}$
Returns:
The log probability

Definition at line 257 of file storm.h.

References spot_shape_diff(), and sq().

{
    using namespace TooN;
    using namespace std::tr1;
    using namespace std;
    //-1 because if the image is 3x3, ie 0,1,2 then 1,1 is the centre.
    //If it is 2x2, ie 0,1 then .5,.5 is the centre
    Vector<2> centre = makeVector((im.size().x-1) / 2.0, (im.size().y-1) / 2.0);

    double logprob_part=0;
    Vector<2> diff = Zeros;
    for(int y=0; y < im.size().y; y++)
        for(int x=0; x < im.size().x; x++)
        {
            Vector<2> d = makeVector(x, y) - centre;

            double mu;
            Vector<2> diff_mu;
            tie(mu, diff_mu) = spot_shape_diff(d, spot_parameters);

            double e = im[y][x] - mu;

            logprob_part += -sq(e);
            diff         += diff_mu * e;
        }
    return make_pair(logprob_part / (2*variance) - im.size().area() * log(2*M_PI*variance)/2, diff / variance);
}
template<class Base >
double log_probability_spot ( const CVD::SubImage< float > &  im,
double  variance,
const TooN::Vector< 4, double, Base > &  spot_parameters
)

See log_probability_spot_hess.

Parameters:
imImage
variance$\sigma^2$
spot_parameters$\Vec{\phi}$
Returns:
The log probability

Definition at line 292 of file storm.h.

References spot_shape(), and sq().

{
    //-1 because if the image is 3x3, ie 0,1,2 then 1,1 is the centre.
    //If it is 2x2, ie 0,1 then .5,.5 is the centre
    TooN::Vector<2> centre = TooN::makeVector((im.size().x-1) / 2.0, (im.size().y-1) / 2.0);

    double logprob_part=0;
    for(int y=0; y < im.size().y; y++)
        for(int x=0; x < im.size().x; x++)
        {
            TooN::Vector<2> d = TooN::makeVector(x, y) - centre;

            double mu = spot_shape(d, spot_parameters);

            double e = im[y][x] - mu;

            logprob_part += -sq(e);
        }
    return logprob_part / (2*variance) - im.size().area() * log(2*M_PI*variance)/2;
}
double log_normal_std ( double  mu,
double  sigma
) [inline]

Compute the standard deviation of a log-normal distribution.

See log_normal().

\begin{equation} \mathrm{Var}[P(x)] = (e^(\sigma^2)-1)e^(2*\mu+\sigma^2) \end{equation}

Parameters:
sigma$ \sigma$
mu$ \mu$
Returns:
The standard deviation

Definition at line 324 of file storm.h.

References sq().

Referenced by brightness_motion_limit().

{
    return sqrt((exp(sq(sigma)) - 1) * exp(2*mu + sq(sigma)));
}
double log_normal_mode ( double  mu,
double  sigma
) [inline]

Compute the mode of a log-normal distribution.

See log_normal().

\begin{equation} \mathrm{Mode}[P(x)] = e^(\mu-\sigma^2) \end{equation}

Parameters:
sigma$ \sigma$
mu$ \mu$
Returns:
The mode

Definition at line 340 of file storm.h.

Referenced by generate_state_parameters_ye_olde(), and FitSpots::try_modifying_model().

{
    return exp(mu - sigma * sigma);
}
double log_log_normal ( double  x,
double  mu,
double  sigma
) [inline]

Log-normal distribution.

This is given by:

\begin{eqnarray} P(x) &=& \frac{1}{x\sigma\sqrt{2\pi}} e^{-\frac{(\ln x - \mu)^2}{s\sigma^2}}\\ \ln P(x) &=& -\frac{(\ln x - \mu)^2}{s\sigma^2} - \ln x - \ln\sigma\sqrt{2\pi}. \end{eqnarray}

Parameters:
xx
mu$\mu$
sigma$\sigma$

Definition at line 355 of file storm.h.

References ln(), and sq().

Referenced by NegativeFreeEnergy::compute_with_mask(), and NegativeFreeEnergy::operator()().

{
    return -sq(ln(x) - mu) / (2*sq(sigma)) - ln(x) - ln(sigma * sqrt(2*M_PI));
}
double diff_log_log_normal ( double  x,
double  mu,
double  sigma
) [inline]

Derivative of the log of the log-normal distribution:

\[ \frac{\partial \ln P(x)}{\partial x} = -\frac{1}{x}\left(1 + \frac{\ln x - \mu}{\sigma^2}\right). \]

.

Parameters:
xx
mu$\mu$
sigma$\sigma$

Definition at line 369 of file storm.h.

References ln(), and sq().

Referenced by FreeEnergyHessian::hessian(), SpotNegProbabilityDiffWithSampledBackground::operator()(), sampled_background_spot_hessian2(), and sampled_background_spot_hessian_ffbs().

{
    return -(1 + (ln(x) - mu)/sq(sigma)) / x;
}
double hess_log_log_normal ( double  x,
double  mu,
double  sigma
) [inline]

Second derivative of the log of the log-normal distribution:

\[ \frac{\partial^2 \ln P(x)}{\partial x^2} = \frac{1}{x^2}\left(1 + \frac{\ln x - \mu}{\sigma^2} - \frac{1}{\sigma^2}\right). \]

.

Parameters:
xx
mu$\mu$
sigma$\sigma$

Definition at line 384 of file storm.h.

References ln(), and sq().

Referenced by FreeEnergyHessian::hessian(), sampled_background_spot_hessian2(), sampled_background_spot_hessian_FAKE(), and sampled_background_spot_hessian_ffbs().

{
    return (1 + (ln(x) - mu - 1)/sq(sigma)) / sq(x);
}
Generated on Wed Nov 28 2012 15:39:12 for ThreeB by  doxygen 1.7.4
